Fire Annunciator Panel Mounting Height

You can get a zone repeater unit if it has to be hidden away or disabled access is required.

Fire annunciator panel mounting height. Manual fire alarm boxes shall be red in color. In terms of appliance location 18 5 5 3 details where ceiling heights do not permit wall mounting at a minimum of 80 in the room size covered by a visual notification appliance of a given value shall be reduced by twice the difference between the minimum mounting height of 80 in. Annunciator location visible from the fire department entrance specify display height for installation for the intended user suggest 1 6 m to centre of display. Manual fire alarm boxes pull stations the height of the manual fire alarm boxes shall be a minimum of 42 inches and a maximum of 54 inches measured vertically from the floor level to the activating handle or lever of the box.

Not less than 150 mm from the ceiling measured from the top of the assembled device top edge of gong if the device is a bell. Usually chest to eye height they have to be seen remember. Annunciator and zone indication 1 except as permitted by sentences 3 to 5 an annunciator shall be installed in close proximity to a building entrance that faces a street or an access route for fire department vehicles that complies with sentence 3 2 5 5 1. Remote control units dgp rcu ttb etc the top of the cabinet shall not be more than 96 above the finished floor level.

A new requirement for the 2019 edition of nfpa 72 also specifies the maximum and minimum mounting heights for control equipment as 6 ft 1 8m and 15 in. Not less than 2300 mm above the floor where ceiling heights allow measured to the centre of the device. And the actual lower mounting height. So as you can see there is no definitive answer as to where a fire alarm control unit needs to be installed.

Ideally its front panel indicators at eye level. It should be at a height where it is easilly accessable and in a prominent position in the building. Fire alarm control units and remote annunciators display and or operating controls shall not be more than 72 above the finished floor level. The ontario building code annunciator and zone indication 3 2 4 9.
